Steel Wires

Mahajan Engg. Works one of the companies  of mahajan group is the a benchmark name when it comes to the manufacturing of steel wires.  The wires are processed with utmost quality standards and are spheroidized annealed to suits various applications. We are currently manufacturing over 30 grades of steel wires mainly SAE 1006, SAE 1008, SAE1010, SAE1015, SAE 1018, SAE 1022,  All kinds of high carbon wires from C35, C45, C50, C55, C60, C65, C70, C75 , C80, boron steel wires such as SAE 15B25, SAE 10B21, 19MnB4, SAE 15B41, and other alloy grades such as En 1A, En 8, En 8D, En 19, En 31, En 42, SCM 420, SAE 8620, SAE 1541, SAE 4140 etc.

We carter to a large number of sectors such as automotive industry including both 2 wheeler, 4 wheelers and heavy commercial vehicles, White good industries, Spring industry, Electrode industry, Fastener industry, ball Bearing industry, Bicycle industry.

Product – Mix and end uses

STEEL QUALITY TYPICAL STEEL GRADE END APPLICATION
Low Carbon 0.14% Carbon Max , 0.60% Mn Max Cable Armouring Wire, Cable Armouring Tape, MS Bolts/Carriage Screw, Wooden Screw
Plane Carbon Drawing Quality & Bright Bar 0.30% to 0.60% Carbon Wire Ropes, Umbrella Rib,Cycle Spoke, Grade I & III Springs,Vibrating Screen,Shutter Spring,Tyre Bead Wire,ACSR,Bright Bars for Auto & Engg Industries
High Carbon Drawing Quality High Carbon Drawing Quality PC Single Wire and Strand, 270K / 250K PC Strand, Piano Wire/ Detonator Spring Wire,Wire Rope, Grade II & III Spring, Spring Washer,ACSR,Needle Wire,Card & Gill Pin for Jute Industries
Low Alloy Steels EN 16 , EN 17, EN 18, EN 19 Hand Tools, Industrial & Bicycle Transmitting Chain
15Cr3, 16MnCr5, SAE 8620, 16CrNi4, 20 Mn2 Link Chain, Forging Industry for Gear , Shafts etc, Bright Bars for mainly Auto and engineering Industry
Spring Steel EN 45A, 60 Si7, 50 CRV4, 58 CRV4 Leaf Spring, Helical Spring
Cold Heading Quality Cold Heading Quality High Tensile Fasteners, Nuts, Self Tapping Screws, Cold Extrusion
Free Cutting EN1A, EN8M, SAE-1146, EN-15AM. EN1A Bright Bars for auto and Engineering Industries
Special Electrodes WJM I , WJM II, AS 3, AS 4 Gas Shielded Electrodes
Bearing Grades En31, SAE52100 Balls & Rollers for Bearing Industries



Specifications

Grade Chemical composition of various steel grades
C% Mn% SI% Cr% Cu% S% P% B% Ni% Mo%
SAE 1006 0.08 Max 0.35 Max 0.10 Max 0.050 Max 0.040 Max
SAE 1008 0.10 Max 0.30-0.50 0.35 Max 0.030 Max 0.030 Max
SAE 1010 0.08-0.13 0.30-0.60 0.35 Max 0.030 Max 0.030 Max
SAE 1015 0.12-0.18 0.30-0.60 0.35 Max 0.030 Max 0.030 Max
SAE 1018 0.15-0.20 0.60-0.90 0.35 Max 0.030 Max 0.030 Max
SAE1022 0.17-.023 0.60-0.90 0.35 Max 0.030 Max 0.030 Max
SAE 10B21 0.18-0.23 0.80-1.20 0.35 Max 0.20 Max 0.030 Max 0.030 Max 0.0005-0.0035
SAE 15B25 0.23-0.28 0.90-1.30 0.35 Max 0.20 Max 0.030 Max 0.030 Max 0.0005-0.0035
SAE 15B41 0.36-0.44 1.35-1.65 0.15-0.30 0.030 Max 0.030 Max 0.0005-0.0035
19MnB4 0.20-0.26 0.80-1.10 0.30 Max 0.30-0.40 Max 0.050 Max 0.40 Max 0.0005-0.0035
C-35 0.30-0.40 0.50-0.80 0.15-0.35 0.050 Max 0.040 Max
HC 46-50 0.46-0.50 0.50-0.80 0.15-0.35 0.035 Max 0.035 Max
HC51-55 0.51-0.55 0.50-0.80 0.15-0.35 0.035 Max 0.035 Max
HC 56-60 0.56-0.60 0.50-0.80 0.15-0.35 0.035 Max 0.035 Max
HC 61-65 0.61-0.65 0.50-0.80 0.15-0.35 0.035 Max 0.035 Max
HC 66-70 0.66-0.70 0.50-0.80 0.15-0.35 0.035 Max 0.035 Max
HC 71-75 0.71-0.75 0.50-0.80 0.15-0.35 0.035 Max 0.035 Max
HC 76-80 0.76-0.80 0.50-0.80 0.15-0.35 0.035 Max 0.035 Max
SAE 1541 0.36-0.44 1.35-1.65 0.15-0.30 0.030 Max 0.030 Max
SAE 4140 0.38-0.43 0.75-1.00 0.20-0.35 0.80-1.10 0.040 Max 0.040 Max 0.15-0.25
SAE-8620 0.18-0.23 0.70-0.90 0.20-0.35 0.40-0.60 0.040 Max. 0.040 Max. 0.40-0.70 0.15-0.25
SCM-420 0.18-0.23 0.60-0.85 0.15-0.35 0.90-1.20 0.030 Max. 0.030 Max. 0.15-0.30
EN-42 0.70-0.85 0.55-0.75 0.10-0.40 0.050 Max. 0.050 Max.
EN-19 0.35-0.45 0.50-0.80 0.10-0.35 0.90-1.50 0.050 Max 0.050 Max. 0.20-0.40
EN-31 0.90-1.20 0.30-0.75 0.10-0.35 1.00-1.60 0.050 Max 0.050 Max
EN 8D 0.40-0.45 0.70-0.90 0.05-0.35 0.060 Max 0.060 Max
